Foam Fatigue Tester

Foam Fatigue Tester

SCHAP’s Foam Fatigue Tester is a single station Pneumatic driven tester.  In the standard configuration, it cycles to a constant load, but also can be supplied with an option for constant displacement. It meets the requirements of ASTM D 3574 -03 “Dynamic Fatigue Test by Constant Force Pounding” section.

A PLC-based controller, with a color touch screen display, works in tandem with a 500 pound-force load cell and a signal conditioner to provide a constant cycle rate of 70 cycles per minute with a verified peak applied force of 750 Newtons (other sizes, rates, and peak forces available on request). This tester compresses the foam against the required grid of vent holes under the foam test sample. This tester is designed for standard square foam samples.

There are several indenter options available, but the standard one is in compliance with the ASTM D3574 requirements.

It is also available in a gantry style, capable of testing any location on mattresses (or other large foam type surface) ranging in size from single to king.

RELATED SPECIFICATIONS

• Air Consumption

  • Using a 6” bore x 4” stroke, single rod cylinder:
  • 2” sample thickness: 22 CFM (6 HP continuous)
  • 4” sample thickness: 29 CFM (8 HP continuous)
  • 70 Cycles Per Minute
  • 500lb Capacity Load Cell
  • 15 Inch Total Sample Hight
  • 28 Inch Sample Width
  • 24 Inch Sample Depth
  • Uses Shop Air – 90 PSI
  • Footprint – 29” x 34” x 36”
  • Voltage – 120v or 240v
  • ASTM Hole Pattern – 15” x 15”
  • Anodized Aluminum
  • Intuitive Touchscreen
  • Load or Displacement Tuning

This Machine can also be ordered or retro-fit with our proprietary Safety Enclosure. CLICK HERE

Rental Options:

This item is available for purchase, rent or lease to own.

Weight69 kg
Dimensions1070 × 1015 × 870 mm
